瑞豐包裝機械

全自動臥式拉鏈袋制袋機
產品詳情

1.      本機采用先進的臺灣威倫觸摸顯示器,先進的PLC電腦程序,采用伺服驅動,自動糾偏控制程序。具有自動計數、斷料自動停機、電眼跟蹤任意長度、失效自動報警、放料采用光電糾偏、磁粉張力控制等。

2.      整機采用變頻調速。具有自動放料、折底、燙刀熱合、點斷、打孔、超聲波焊燙點、振動盤高速自動上拉頭、硅膠板出料等功能。

3.      本機具有臥式燙拉鏈和自動上拉鏈頭兩大特點,拉鏈燙合更加穩定、機器高速穿拉鏈頭效率更高,節省人工和物力。

Main characteristic

1.      this machine adopts advanced Taiwan Weinview touch display, advanced PLC computer program using servo drive, automatic correction control program. With automatic counting, automatic shutdown off material, electric eye tracking anyltaly length, failure alarm, discharge using optical correction, magnetic powder tension control.

2.      the machine adopts frequency control with automatic discharge, fold the bottom, hot knife welding, cutting-off, drilling, ultrasonic welding hot spot, vibration speed automatic slider, silicone plate discharging other functions.

3.      the machine at the discharge part of design of the cooling system, the production of the bag section, after cooling, better sealing.

4.      the machine has horizontal hot zipper and zipper automatic two features, zipper hot together more stable, higher-speed machine wear zipper efficiency, save labor and material resources.

主要技術參數

The main technical parameters

  型號

Model

RF-W700

RF-W800

RF-W900

  材料

LDPE/PP/OPP/BOPP/EVA

LDPE/PP/OPP/BOPP/EVA

LDPE/PP/OPP/BOPP/EVA

LDPE/PP/OPP/BOPP/EVA

生產速度

Production Speed

40-80PCS/min

40-80PCS/min

40-80PCS/min

制袋寬度

Bag-making width

300-1000mm

30-1000mm

30-1000mm

制袋長度

Bag-making Length

50-700mm

50-800mm

50-900mm

厚度

Thickness

0.03-0.2mm

0.03-0.2mm

0.03-0.2mm

上拉頭速度

The speed of slider mounting

40-80pcs/min

40-80pcs/min

40-80pcs/min

電源

Power Supply

220V-380V

220V-380V

220V-380V

總功率

Total Power

8KW

8.5KW

9KW

外形尺寸

Overall Dimension(L*W*H)

8000*1250*1950

8000*1350*1950

8000*1450*1950
